廈門唯恩電氣有限公司（WAIN ELECTRICAL）是集研發、生產、銷售工業連接器（重載連接器）的高新技術企業。
唯恩電氣以質量及技術領先為目標，擁有塑膠射出、五金產線、壓鑄產線、電鍍產線、裝配及模具廠等現代化作業場所，另外擁有產品研發，及產品性能檢測實驗室，其實驗室符合UL認證規範，多項技術專利。
WAIN致力於創建世界連接器行業的一流品牌。
HA Series
Compact Standard Connector
-
Number of contacts:3,4,10,16,
32(2X16)+PE
-
Rated Current:10Amp @ 230V/400V
16Amp @ 250V
-
Working Temperature:-40°C...+125°C
HEE Series
High density connector
-
Number of contacts: 10,18,32,40,46,64,64(2x32), 92(2x46)+PE
-
Rated Current:16Amp @ 500V
-
Working Temperature:-40°C...+125°C
HE AV Series
Extendible connector
-
Number of contacts:6,10,16,24+PE
-
Rated Current:16Amp @ 500V
-
Working Temperature: -40°C...+125°C
矩形重載連接器 Rectangle Heavy Duty Connectors
HD HDD Series
Ultra-high density connector
-
Number of contacts (HD Series):7,8,15,25,40,50(25x2),
64,80(40x2),128(64x2)+PE
-
Number of contacts (HDD Series):24,42,72,108,144(72x2),
216(108x2)+PE
-
Rated Current:10Amp @ 250V
-
Working Temperature: -40°C...+125°C
Crimp contacts冷壓針
5A / 9A / 10A / 16A / 25A / 30A / 40A
70A / 100A / 200A / 250A / 350A / 650A
10A Stampede Contacts
Relay Pins
Signal Pins
Power Pins
HVE Series
High voltage connector
-
Number of contacts:3,6,10,12,20+PE
-
Rated Current:16Amp @ 830V
-
Working Temperature:-40°C...+125°C
HVES Series
High voltage connector
(spring piece connector)
-
Number of contacts:3,6,10,12,20+PE
-
Rated Current:16Amp @ 830V
-
Working Temperature:-40°C...+125°C
HSB Series
35A heavy-current connector
-
Number of contacts:6,12+PE
-
Rated Current:35Amp @ 400V / 690V
-
Working Temperature:-40°C...+125°C
HK Series
Combination connector
-
Number of contacts:8/24+PE
-
Rated Current:
16Amp @ 400V (Power area)
10Amp @ 250V (Signal area)
-
Working Temperature:-40°C..+125°C
HM Series
Flexible and combined connector
-
2, 3, 4, 6, 12(6 x 2) Modules
-
Module Types:
Power / Signal / Communication
Ethernet / USB / Pneumatic / Fiber
HQ Series
Compact connector
-
Number of contacts:
2 + PE, 40A / 400V
4/2 + PE, 40A / 400V
5+ PE, 16A / 203V
7+ PE, 10A /400V
8+ PE, 10A / 500V
12 + PE, 10A / 400V
17 + PE, 10A / 250V
21, 6.5A / 50V
-
Working Temperature: -40°C...+125°C
圓形連接器 Circular Connectors
M8 Circular connectors
Standards: IEC-61076-2-104
-
Versions with assembly
-
Thread locking M8x1
-
Screw-, solder termination
-
Connector moulded on cable
-
Degree of protection IP67/IP65 1)
-
Cable length 2m and 5m (PVC and PUR)
-
Other cable length upon request, MOQ is 200pcs
-
If needed, the cable material can be customized according to your requirements
Heavy-current cable butting
connector
-
The male plug is provided with a quick-connect nutanti-rotation device to play the role of nut anti-rotation.
-
Increase the assembly clearance of pin to preventdamage of connector caused by thermal expansion and cold contraction.
-
Add a variety of coding to the insertion of male and female plugs to avoid wrong insertion.
-
Color codes distinguish three - phase cables.
-
Double crown spring is adopted to increase the contact area of male and female pins.
-
Protection against electric shock.
-
Add the wire size mark to the pin.
M12 Circular Connector,A-coded
Standards: IEC-61076-2-101
-
Mounting or molding versions
-
Assembly possible and moulded versions
-
Thread locking M12x1
-
Screw-/wire clamp connection
-
Shield connection with shield ring/iris type spring
-
Cable length 1.5m and 5m (PVC and PUR)
-
Other cable length upon request, MOQ is 200pcs
-
If needed, the cable material can be customized according to your requirements
-
Degree of pretection IP67/IP68
-
Transparent housing for PCB with LED
M23 Circular connector-Signal
Connection
-
Size R 23
-
Outer diameter 26 mm
-
High contact density
-
Very robust hoods and housings
-
Corrosion resistant
-
Excellent EMC properties (with continuous shielding)
-
Quick and easy assembly
-
Vibration resistant screw locking system
-
Up to 19 contacts, 25 V~ / 60 V-
-
Ideal for applications such as measurement andautomatic control
M40 Circular power connectors
M12 Circular Connector,D-coded
Standards: IEC-61076-2-101
-
Shieldable/360° shield connection with
-
shield ring or iris type spring
-
Thread locking M12x1
-
Screw connection
-
Degree of protection IP67
-
D-coded for Ethernet/Profinet
-
Transmission features DIN EN 50173
-
CAT 5,screw termination
-
Anti-loose spring with nut
M12 distributor
-
Number of contacts:3 / 4Pins @ 4A / 250V
Sensor junction box
-
4 - Pole / 5 Pole
10~30V DC 2A/9A
MR23 Circular power connectors
-
Size R 23
-
Outer diameter 26 mm
-
High contact density
-
Very robust hoods and housings
-
Corrosion resistant
-
Excellent EMC properties (with continuous shielding)
-
Quick and easy assembly
-
Vibration resistant screw locking system
-
Up to 19 contacts, 25 V~ / 60 V-
-
Ideal for applications such as measurement and automatic control
MR23 Circular power connectors
-
Size R 23
-
Outer diameter 26 mm
-
High contact density
-
Very robust hoods and housings
-
Corrosion resistant- Excellent EMC properties (with continuous shielding)
-
Quick and easy assembly
-
Vibration resistant screw locking system
-
Up to 19 contacts, 25 V~ / 60 V-
-
Ideal for applications such as measurement and automatic control
Power connector
(National grid standard)
tools
